| 是否进口：否 | 产地：深圳 | 品牌：品赞/G-Switch |
| 型号：GT-TC041X-H010-L1X | 最高电压：12V | 订货号：GT-TC041X-H010-L1X |
| 额定发热电流：50MA | 用途：影音产品，电脑产品 | 物料编号：GT-TC041X-H010-L1X |
| 加工定制：否 | 货号：GT-TC041X-H010-L1X | 3C额定电压范围：440V以上 |
| 是否跨境货源：否 |
Specification
FUNCTION: Momentary action
CONTACT ARRANGEMENT: 1 make contact = SPST, N.O.
Electrical
MAXIMUM VOLTAGE: 15 VDC
MAXIMUM CURRENT DC: 20 mA
DIELECTRIC STRENGTH: 250 VA C (1mn)
CONTACT RESISTANCE: 鈮� 100 m惟
INSULATION RESISTANCE: 鈮� 100 M惟
BOUNCE TIME: 鈮� 10 ms
SWITCH TRAVRL锛�0.25卤0.1mm
Environmental
OPERATING TEMPERATURE: -20藲C to 70藲C
